Introduction To Ductless Fume Cupboards
Efficient ventilation systems are critical to laboratory safety. Ductless fume cupboards are a particularly effective and adaptable way to handle dangerous vapors and fumes. These units provide a small, affordable substitute for conventional fume hoods because they are made to filter and circulate air without the need for ductwork.The products are a great tool for distributors of lab equipment, builders, and contractors looking to improve safety and compliance. Our specialty at Xi'an Xunling Electronic Technology Co., Ltd. is creating dependable, high-quality products that are customized to satisfy the various needs of our customers across the globe.
Parameters
Parameter | Description | |||
---|---|---|---|---|
Ductless Fume Cupboards |
External Dimension ( mm) Width*Depth*Height |
Internal Dimension ( mm) Width*Depth*Height |
Customized mm | |
DSS800 |
800*620*2070 |
781*574*934 |
Customized mm | |
DSS1000 |
1000*620*2070 |
981*574*934 |
Customized mm | |
DMS1275 |
1275*620*2070 |
1256*574*934 |
Customized mm | |
DMS1600 |
1600*620*2070 |
1581*574*934 |
Customized mm | |
DLS1600 |
1600*790*2070 |
1581*744*934 |
Customized mm | |
Filtration System | Pre Filters + HEPA Filters + Activated Carbon Filters | |||
Airflow Rate |
0.3-0.7m/s |
|||
Filtration Chemicals | Acids fumes, Alkali fumes, Organic Solvents Fumes, Ammonia, Formaldehyde, Powders, Micron Particulates...... | |||
Monitor and Alarming | Real-time | |||
LCD Display | Shows temperature, humidity, air quality, and filters status | |||
Noise Level | ≤52 dB |
Ductless Fume Cupboards Features
Our Ductless Fume Cupboards are engineered with safety, efficiency, and ease of use in mind. Key features include:
- Advanced Filtration System: Utilizes HEPA filters to capture 99.97% of particles as small as 0.3 microns, ensuring a safe working environment.
- Low Noise Operation: Designed to minimize disturbance, our units operate at or below 50 dB, ideal for laboratories where concentration is key.
- Energy Efficiency: With a power consumption range of 110-220V, 50/60Hz, our products are not only effective but also economical.
- Compact Design: Perfect for laboratories with limited space, our units are designed to be compact without compromising on performance.
Application
Because of their great adaptability, ductless fume cupboards can be used successfully in a variety of settings, such as:
- Labs: These fume cupboards are ideal for a variety of labs where dangerous materials or chemicals are regularly used, including chemistry, biology, and physics labs. By filtering out dangerous vapors and fumes, they offer a crucial safety solution and guarantee a safe working environment for technicians and researchers.
- Pharmaceutical Research: The products are essential for protecting researchers who handle strong and occasionally volatile substances in pharmaceutical research settings. The sophisticated filtration system efficiently eliminates potentially dangerous materials from the air, establishing a safe and regulated setting for the creation and testing of novel drugs.
- Industrial Settings: Because workers in industrial facilities may be exposed to hazardous dust, fumes, or particles, the products are also very helpful in these settings. These fume cupboards contribute to a safer, cleaner workplace and worker health protection in settings such as production lines, workshops, and manufacturing plants by filtering out harmful airborne contaminants.
Ductless Fume Cupboards Video ;
Why Choose Us?
At Xi'an Xunling Electronic Technology Co., Ltd, we pride ourselves on our commitment to quality, safety, and customer satisfaction. Our products are designed and manufactured with the highest standards in mind, ensuring reliability, efficiency, and compliance with international safety standards. With a strong focus on after-sales service, including installation, training, and maintenance support, we strive to build long-lasting relationships with our clients.
Certification
Our products are certified to meet or exceed international standards, including ISO, CE, and NFPA, ensuring compliance and safety in laboratories worldwide.
FAQ
Q1: How often should the filters in a the fume cupboard be replaced?
A1: Filter replacement depends on usage but typically ranges from 1-3 years.
Q2: Can the products be customized for specific applications?
A2: Yes, we offer customization options to meet the unique needs of our clients.
Q3: What is the typical lead time for delivery of a the product?
A3: Lead times vary but generally range from 2-6 weeks depending on the order and shipping location.
Contact Us
For more information on our products or to inquire about customization options, please do not hesitate to contact us at xalabfurniture@163.com. Our dedicated team is here to assist you in finding the perfect solution for your laboratory needs.
By choosing Xi'an Xunling Electronic Technology Co., Ltd for your ductless fume cupboard requirements, you are not only investing in a high-quality product but also in a safer, healthier laboratory environment. Let us help you make the laboratory world cleaner, safer, and healthier.
